Description
Built for modern XC racing, this full-composite flyer tackles steep singletrack climbs and technical descents with speed and control. With FlexPoint Pro rear suspension and race-ready geometry, it puts you at the front of the pack.
Ultra-efficient
Advanced composite frameset is 241g lighter than previous generation. The bottom bracket area is stiffer for faster acceleration, and a steeper seat tube puts the rider in an efficient climbing position.
Superior control
FlexPoint Pro suspension delivers 100mm of smooth, active rear travel. The frameset features modern XC geometry including a slacker 67.5-degree head tube and 110mm suspension fork for technical descents.
29er stability and speed
Frame geometry and suspension are optimised for fast and stable 29-inch wheels. A longer reach and modified cockpit including a 35mm composite handlebar and alloy stem further boost balance and stability on XC terrain.
AT A GLANCE
- Frame: Advanced-Grade Composite front and rear triangles
- Fox 34 Float SC Performance Elite 110mm travel forks
- Giant XCR 1 29 carbon wheelset
- SRAM GX T-Type 12 speed drivetrain with SRAM XO-T-Type crankset including power meter
- Shimano Deore XT hydraulic disc brakes
- Giant Contact Switch AT dropper post
- Maxxis Aspen 29x2.4 tubeless ready tyres
Sizing (Rider Height)
Small: 163cm - 172cm
Medium: 171cm - 180cm
Large: 179cm - 188cm
X-Large: 187cm - 198cm
BIKE SPECSFRAME
Advanced-Grade Composite front and rear triangles, 100mm FlexPoint Pro suspension, UDH hanger, 12x148mm thru-axle, 55mm Chainline
FORK
Fox 34 Float SC Performance Elite, 110mm, FIT4 damper, Boost 15x110 Kabolt, 44mm offset, 3 position lockout, custom tuned for Giant
REAR SHOCK
Fox Float SL Performance Elite, 3 position lockout, custom tuned for Giant
HUBS
Front: Giant XC alloy, CenterLock. Rear: Giant XC alloy, DT350 internal, 54t ratchet system, CenterLock
SPOKES
Sapim Laser stainless steel
RIMS
Giant XCR 1 30 Carbon WheelSystem, 30mm inner width
TYRES
Maxxis Aspen 29x2.4, foldable, TLR, EXO, tubeless
CRANKSET
SRAM XO T-Type, Powermeter 32t, 55mm chainline
BOTTOM BRACKET
SRAM DUB, press fit
SHIFT LEVERS
SRAM AXS Pod, 1x12 speed
DERAILLEURS
SRAM GX Eagle T-Type AXS 12 speed
CASSETTE
SRAM GX, T-Type 10x52 12 speed
CHAIN
SRAM GX T-Type
BRAKES
Shimano Deore XT BR-M8100, hydraulic, Shimano RT-64 rotors [F]180mm, [R]160mm
HANDLEBARS
Giant Contact SLR XC Flat, composite, 35mm
STEM
Giant Contact SL XC, 35mm
SADDLE
Fi'zi:k Antares R5 with K:ium rails
SEATPOST
Giant Contact Switch dropper, remote
PEDALS
N/A
EXTRAS
Tubeless prepared, 2.4" max tyre size, 34t max chainring size, Giant/MRP CS chain guide
|
* Specifications are subject to change without notice
