Description
With the capabilities of a full blown downhill rig, Stumpjumper EVO Alloy is set up for gnarly terrain and features the same all-new design as its carbon brethren including an adjustable head tube angle, 150mm of performance tuned travel, the and SWAT™ Door in-frame storage. the 29" front and 27.5" rear wheel setup offers the best of both worlds - traction and agility on the trail.
With a bullet-proof SRAM GX Eagle 12-speed drivetrain, stout 30mm-wide alloy wheels, and Rx Tuned RockShox suspension, there’s no trail too rowdy.
SIZING:
* Specifications are subject to change without notice
With a bullet-proof SRAM GX Eagle 12-speed drivetrain, stout 30mm-wide alloy wheels, and Rx Tuned RockShox suspension, there’s no trail too rowdy.
SIZING:
S1: Suit 150-160cm rider height
S2: Suit 157-173cm rider height
S3: Suit 165-180cm rider height
S4: Suit 173-188cm rider height
S5: Suit 178-193cm rider height
S6: Suit 188-203cm rider height
BIKE SPECSFrame
M5 Alloy chassis and rear-end, asymmetrical design, 29/27.5" Trail Geometry with S-Sizing, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel. Rear Shock: Rock Shox Super Deluxe Ultimate, Rx Trail Tune,RC2T Damper, Hydraulic Bottom Out control
Fork
RockShox Lyrik Ultimate, Charger 3 RC2 W/ButterCups, 15x110mm, 44mm offset, S1: 150mm of travel, S2-S6: 160mm of travel
Seat Binder
Alloy, quick release, 38.6
SeatPost
OneUp, Dropper Post-V2, MMX lever, 34.9
Stem
Deity, 35.0mm
Saddle
Bridge Comp, Hollow Cr-mo rails, 155/143mm
Handlebars
Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 30mm rise, 800mm, 35mm clamp
Grips
Deity Grips
Brakes
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline
Shift Levers
SRAM GX, trigger, 12-speed
Derailleurs
Rear: SRAM GX Eagle, 12-speed
Cassette
SRAM XG-1275, 12-speed, 10-52t
Chain
SRAM GX Eagle, 12-speed
Crankset
SRAM GX Eagle Alloy, DUB, 165/170/175mm, 32t
Bottom Bracket
SRAM DUB, BSA 73mm, Threaded
Pedals
N/A
Rims
Roval Traverse 29/27.5 Alloy, 30mm inner width, hand-built, 2Bliss Ready
Hubs
Front: Roval, sealed cartridge bearings, 15x110mm spacing, 28h. Rear: Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
Spokes
DT Swiss Competition Race
Tyres
Front: Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3". Rear: Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 29x2.3"
Inner Tubes
Standard, Presta valve
Weight
15.5kg
|
