Description
The all-new 2023 Giant Liv Embolden E+ 2 features a 75NM SyncDrive Sport 2 motor, new fully integrated EnergyPak Smart 625Whr battery, handlebar-mounted RideControl Dash and Smart Assist Technology let you ride farther, faster and more efficiently.
Agile and Functional
The Embolden E+ delivers more aggressive travel, 125mm FlexPoint rear suspension and 140mm upfront making it an all-round backcountry adventure machine. The new SyncDrive Sport 2 motor with 75 Nm of torque and max 400% support and the EnergyPak Smart 625 battery offers the longest possible range - the Embolden E+ delivers the power you need to explore new terrain.
Built for You
Liv’s women first design philosophy and suspension tuned for female riders provide a confidence-inspiring, predictable and maneuverable ride.
X-Small: 152cm - 163cm
Small: 158cm - 169cm
Medium: 164cm - 175cm
Large: 170cm - 181cm
* Specifications are subject to change without notice
Agile and Functional
The Embolden E+ delivers more aggressive travel, 125mm FlexPoint rear suspension and 140mm upfront making it an all-round backcountry adventure machine. The new SyncDrive Sport 2 motor with 75 Nm of torque and max 400% support and the EnergyPak Smart 625 battery offers the longest possible range - the Embolden E+ delivers the power you need to explore new terrain.
Built for You
Liv’s women first design philosophy and suspension tuned for female riders provide a confidence-inspiring, predictable and maneuverable ride.
- Range: 55-180km depending on terrain
- SyncDrive Sport 75Nm motor, powered by Yamaha with 625Wh battery
- ALUXX SL grade grade aluminum frame 125mm travel and SR Suntour XCR 34 Air LO-fork with 140mm travel
- Easy-to-use and very reliable Shimano Deore 10 speed gearing
- Powerful Tektro hydraulic disc brakes
- Maxxis Minion tubeless ready tyres
X-Small: 152cm - 163cm
Small: 158cm - 169cm
Medium: 164cm - 175cm
Large: 170cm - 181cm
BIKE SPECSFRAME
ALUXX SL-Grade aluminium, 125mm travel FlexPoint suspension system, 12x148mm thru-axle, UDH hanger
FORK
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
REAR SHOCK
SR Suntour Raidon R, custom tuned
HUBS
Giant eTracker Boost, [F] 15mm Thru-Axle [R] 141mm QR
SPOKES
Stainless Steel
RIMS
Giant AM 27.5" / 29", Tubeless ready, 30mm inner width (XS: 27.5+ / S-L: 29)
TYRES
Maxxis Minion DHF 29x2.4"/ 27.5x2.4" foldable, 60tpi, EXO, Tubeless Ready (XS: 27.5, S-L: 29)
CRANKSET
FSA Comet E-Bike crank arm set, FSA MegaTooth Direct-mount 1X steel 36T
BOTTOM BRACKET
FSA sealed
SHIFT LEVERS
Shimano Deore LinkGlide 10 speed
DERAILLEURS
Rear: Shimano Deore LinkGlide, 10-speed. Front: MRP HD2 co-moulded chain guide
CASSETTE
Shimano CS-LG400-10, 11-43T, 10-speed LinkGlide
CHAIN
Shimano, LinkGlide, CN-LG500
BRAKES
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm rotors
HANDLEBARS
Giant Connect TR Riser 31.8mm. Grips: Liv Tactal single lock-on
STEM
Giant Contact
SADDLE
Liv Sylvia E
SEATPOST
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
PEDALS
N/A
MOTOR
SyncDrive Sport 2, 75Nm, powered by Yamaha
BATTERY
EnergyPak Smart removable 625Wh, 36V Integrated Lithium-Ion, range extender compatible
DISPLAY
RideControl Dash, full colour LCD screen
EXTRAS
Lock: Torx 25 Battery Lock with built-in Torque limiter. EnergyPak 4A smart charger compact.
|
